DI 7. Low level float
The low level float is used to signal low level or to stop the pumps if you have activated stop pump function. If
the “stop pump” function is not used, only an alarm is given but the pumps will not stop.
DI 8. High float Overflow
In 2 pump applicatioin thi input is only used for High level float
The high level float is used to signal high level and if the start pump option is activated, to start the pump. If you
don’t activate the “start pump” function only alarm will be given, but not start the pumps.
t
In 3 pump applications this input can be used either as a high float input (as shown above )or as
overflow input
If the input is used as Overflow input input it will measure when the stationis in overflow, number of
overflows and total overflow time
t
Here you set if the input is used or not.
Here you set the signal type NO or NC
Here you set the alarm function Yes or No
Here you set if the pumps are going to be stopped
Yes or No (backup operation or with levelswitch operation).
Here you set the alarm delay to prevent false alarms due to
unstable surface in the pit.
-.
-
-
- Här anger man larmfördröjning för att undvika
falska signaler pga. vågskvalp i stationen.
7 . L o w f l o a t ►
◄◄
F u n c t i o n
◄◄◄ i n u s e
S i g n a l t y p e
◄◄◄ N O
▼▲
A l a r m f u n c t i o n
◄◄◄ Y e s
▼▲
S t o p p u m p
◄◄◄ N o
▼▲
A l a r m d e l a y
◄◄◄ 5
▼▲
- Here you set if the input is used or not.
For three pump application you can set the function
as high level float or overflow float.
- Here you set the signal type NO or NC
- Here you set the alarm function : Yes or No
- Start pump: Yes or No (For backup operation or
levelswitch operation).
- Here you set the alarm delay to prevent false
alarms due to ripple on the surface in the pit.
8 . H i g h f l o a t ►
◄◄
F u n c t i o n
◄◄◄ h i g h f l o a t
i t w i l l e l e v e l f l o a t
S i g n a l t y p e
◄◄◄ N O
▼▲
A l a r m f u n c t i o n
◄◄◄ Y e s
▼▲
S t a r t p u m p
◄◄◄ N o
▼▲
A l a r m d e l a y
◄◄◄ 5
▼▲
- Here you set if the input is used or not.
For three pump application you can set the function
as overflow float or not used
-Here you set the signal type NO or NC
- Here you set the alarm function : Yes or No
- Here you set the alarm delay to prevent false
alarms due to ripple on the surface in the pit.
8 . H i g h f l o a t ►
◄◄
F u n c t i o n
◄◄◄ o v e r f l o w
w i l l e l e v e l f l o a t
S i g n a l t y p e
◄◄◄ N O
▼▲
A l a r m f u n c t i o n
◄◄◄ Y e s
▼▲
▼▲
A l a r m d e l a y
◄◄◄ 5
