MANUAL PC-200
Ver. 2.12.xx/10/22/2010-UK
Page 18 (61)
DI 9. Block / Overflow
For2 and 3 pump applications this input can be used for external blocking of the pumps
External block is a signal input which will stop all pumps when activated with a built in delay between each
pump.
Alternativ
Fot 3 pump applications this input can be used as Overflow input,( if DI8is used for High level float)
If the input is used as Overflow input input it will measure when the stationis in overflow, number of
overflows and total overflow time
Alternativ
DI 10. Attendance check (the settings for this function are made under Station settings \ attendance
check. chapter 5.4.5)
F u n c t i o n
◄◄◄ E x t . B l o c k
B l o c k o v e r f l o w
9 . B l o c k / O v e r f l ►
◄◄
F u n c t i o n
◄◄◄ p e r s o n a l
1 0 . A t t e n d c h e c k ►
◄◄
See further details in Station settings – Attendance check
S i g n a l t y p e
◄◄ N C
A l a r m f u n c t i o n
◄◄◄ N o
A l a r m d e l a y [ s ]
◄◄◄ 1 . 0
▼▲
t
▼▲
▼▲
- Here you set if the input is used Ext. Block or not used.
- Here you set the signal type NO or NC
- Here you set the alarm function Yes or No
- Here you set the alarm delay.
-.
-
-
▼▲
F u n c t i o n
◄◄◄ O v e r f l o w
B l o c k o v e r f l o w
9 . B l o c k / O v e r f l ►
◄◄
S i g n a l t y p e
◄◄ N C
A l a r m f u n c t i o n
◄◄◄ N o
A l a r m d e l a y [ s ]
◄◄◄ 1 . 0
▼▲
t
▼▲
▼▲
- Here you set if the input is used for overflow or not.
- Here you set the signal type NO or NC
- Here you set the alarm function Yes or No
- Here you set the alarm delay.
-.
-
-
