Ducati MULTISTRADA V4 User Manual

Changing the Riding Mode
●
Press and hold the MODE/ENTER  (3) for
a long time.
●
The dedicated screen is displayed (Fig 76) where,
using  (1) and (2), it is possible to scroll
through the available Riding Modes and display
the parameters with the relevant set values.
●
Press the MODE/ENTER  (3) to confirm.
Select "Exit" and press MODE/ENTER  (3) to
quit the screen without making any changes.
As soon as the new Riding Mode is confirmed, the
instrument panel checks the following conditions:
●
If speed is lower than or equal to 5 km/h (3 mph)
and  control is open, the message Close
 is displayed; the new Riding Mode is
confirmed and stored only when  control
is closed and then the main screen is displayed.
●
If speed is lower than or equal to 5 km/h (3 mph),
 control is closed but brakes are
actuated, the message Release brakes is
displayed. The new Riding Mode is confirmed
and stored only when brakes are released and
then the main screen is displayed.
●
If both of the above conditions occur, the
message "Close  and release brakes" is
1
3
2
Fig 75
0
km/h
Engine High
DTC 4
ABS 2
DWC 2
DQS Off
SPORT
TOURING
ENDURO
URBAN
Exit
Fig 76
98

Ducati MULTISTRADA V4 Specifications

General

Displacement	1, 158 cc
Power	170 hp (125 kW) @ 10, 500 rpm
Torque	125 Nm (92 lb-ft) @ 8, 750 rpm
Transmission	6-speed with Ducati Quick Shift (DQS) up/down
Bore x Stroke	83 mm x 53.5 mm
Compression Ratio	14:1
Front Wheel Travel	170 mm (6.7 in)
Rear Wheel Travel	180 mm (7.1 in)
Front Tire	120/70 ZR19
Rear Tire	170/60 ZR17
Wheelbase	1, 567 mm (61.7 in)
Dry Weight	215 kg (474 lb)
Curb Weight	240 kg (529 lb)
Fuel Capacity	22 l (5.8 US gal)
Engine Type	V4 Granturismo, 4-cylinder, liquid-cooled
Fuel Injection	Electronic fuel injection system, Øeq 46 mm throttle bodies
Exhaust	Single stainless steel muffler with catalytic converter and 2 lambda probes
Final Drive	Chain
Frame	Aluminum monocoque
Front Brake	2 x Ø 330 mm semi-floating discs, radially mounted Brembo Monobloc 4-piston calipers
Rear Brake	Ø 265 mm disc, 2-piston caliper
Seat Height	Adjustable 840-860 mm (33.1-33.9 in)
Safety Equipment	Cornering ABS, Ducati Traction Control
Standard Equipment	Cruise Control, TFT color display
