Duke FLEXIBLE BATCH BROILER - Replacement Parts List

31 of 35
Revised:
April 1, 2007
FLEXIBLE BATCH BROILER
RESTAURANT
EQUIPMENT
MANUAL
V. Replacement Parts List
ITEM #
DESCRIPTION
P/N
1 SWITCH,MAIN POWER 175503
2 BURNER,INFRARED 175504
3 BURNER,TUBE,J STYLE (NATURAL GAS UNIT ONLY) 175505
4 BURNER,TUBE,J STYLE (LP GAS UNIT ONLY) 175693
5 MOTOR-CONVEYOR 175506
6 SPROCKET, B21X3/8 BORE (MOTOR) 175517
7 SHAFT,DISCHARGE SIDE 175037
8 SHAFT,RIGHT SIDE 175038
9 CAPACITOR,MOTOR-CONVEYOR 175507
10 MODULE IGNITION (LOWER BURNER) 175508
11 MODULE IGNITION (UPPER BURNERS) 175509
12 TRANSFORMER,40VA, 120VAC-24VAC 175516
13 PROBE,TEMP., C-CHAMBER 175518
14 LIGHT, COOK 175550
15 RELAY - SOLID STATE 175519
16 CHAIN, DRIVE 175551
17 CONTROLLER 175575
18 GASKET, CONTROL BEZEL 175510
19 GASKET, BLOWER INLET 175511
20 BLOWER, DAYTON 60HZ 115V 175524
21 HOSE, BLOWER 175532
22 ORIFICE HOLDER, IR 175542
VALVE,NAT-GAS,COMBO 120 V (NATURAL GAS UNIT ONLY) 175531
VALVE,LP-GAS,COMBO 120 V (LP GAS UNIT ONLY) 175766
ORIFICE LOWER BURNER, #31 (NATURAL GAS UNIT ONLY) 175734
ORIFICE LOWER BURNER, #49 (LP GAS UNIT ONLY) 175737
ORIFICE, IR, FRONT, #40 (NATURAL GAS UNIT ONLY) 175735
ORIFICE, IR, FRONT, #52 (LP GAS UNIT ONLY) 175767
ORIFICE, IR, REAR, #36 (NATURAL GAS UNIT ONLY) 175736
ORIFICE, IR, REAR, #51 (LP GAS UNIT ONLY) 175768
27 ORIFICE HOLDER 3/8 COMP. STRGHT X BULKHEAD 175545
28 TUBING-TEE TO IR,KIT 175476
29 TUBING-TEE TO VALVE,KIT 175477
30 TUBING-LOWER BURNER TO VALVE,KIT 175478
31 SENSOR-LOWER BURNER 175534
32 SENSOR-IR BURNER 175535
33 IGNITER 175536
34 IGNITION SUPPRESSION CABLE-IR 175537
35 IGNITION SUPPRESSION CABLE-LOWER 175538
36 CHAIN, COOK 175674
37 BUSHING BLOCK, CONVEYOR 175525
38 LOADER TRAY 175430
39 LOADER MOUNTING BRACKET 175438
23
24
25
26
