Operating Instructions For TD/TAD4 Dual Fuel Burner
June 13 45 of 165 TD/TAD4 Manual Rev 4
6 10 14 18 21 24 MAX
40 - 7 11 18 26 37 49 150 2.5
50 - 9 14 22 33 47 61 180 2.85
60 - 11 17 27 40 58 74 200 3.15
70 16 22 30 43 56 72 86 210 3.2
80 18 24 34 48 64 83 98 230 3.2
90 20 27 37 54 72 94 110 254 3.2
100 22 30 42 60 80 105 122 270 3.2
112 24 33 46 67 90 118 137 290 3.2
125 27 36 52 76 103 135 153 320 3.3
140 31 42 59 86 117 152 172 380 3.35
160 35 48 67 98 132 175 196 430 3.5
180 40 54 76 112 150 195 220 460 3.6
200 44 60 86 126 170 220 245 550 4
225 48 67 96 143 192 250 276 600 4
275 58 80 118 175 240 310 337 700 4
300 62 88 130 195 270 350 368 750 4
330 67 96 145 220 300 395 405 800 4
360 73 106 160 240 335 - 440 870 4
400 79 117 180 266 375 - 490 900 4
450 89 133 198 296 420 - 557 960 4
500 98 148 220 333 467 - 612 1025 4
550 108 162 248 367 514 - 673 1100 4
625 124 184 281 417 584 - 765 1200 4
700 138 209 315 464 648 - 857 1300 4
ATOMIZER
NUMBER
RECOMMENDED
MAXIMUM
TURN-DOWN RATIO
PUMP
OUTPUT
RETURN PRESSURES IN BAR
OUTPUTS IN KILOGRAMS/hr
CAPACITY TABLES FOR
TYPE ART114/1400 RETURN FLOW NOZZLES
Supply pressure - 30 bar Viscosity - 5cSt (35 secs Redwood) Maximum output with return closed.
