dunphy TD - Burner Details and Power Curve

12 of 165
1.5 Burner details and power curve
*1 – Based on Nat. Gas C.V 10.4 kW/m3
*2 - Fitted with a Ratiotronic 6000 System
BURNER
Firing Rate kW
GAS
VOLUME
(m3/HR)*1
FIRING MODE OPTIONS
Fan
Motor
KW
Pump
Motor
kW
Voltage
Hz
Ph
Running
Current
Starting
Current
TYPE
MIN
MAX
MIN
MAX
Mod
Gas
High /
Low Oil
High /
Low
Electronic
Modulation
*2
TD410Z
600
4500
58
433



7.5
2.2
380-420
50
3
23 Amp
48 Amp
TD415Z
800
5300
77
510


11.0
2.2
380-420
50
3
32 Amp
64 Amp
TD420Y
1250
6200
120
596


15.0
2.2
380-420
50
3
39 Amp
88 Amp
