6 Component Setup Parameters
Before the commissioning process of the burner can take place, there are certain components like
the Ratiotronic 6000, inverter (when fitted), etc, which will need to be setup. The burner should be
factory set; however, if the parameters have been erased for whatever reason, then this section can
be used as a starting point. Please note that a fuel / air profile will not have been setup. Please also
note that this parameter set should be used in conjunction with the manual.
6.1 Ratiotronic 6000
Option
Value
Description
Comments
0.1
xxx
Site passcode
last 3 digits of burner serial number
0.2
0
Serial communications control address
0.3
0
Reset hours run
0.5
0
Language Select
0.7
1
IsoComsAddress
0.8
2
IsoComsSetting
1.0
5
Power up option
5=ignore alarms for 5 seconds at
power up
1.1
1
Keyboard auto/manual enable
1.2
0
Fault mute input enable
1.3
0
External profile select enable
1.4
0
Gas valve proof of closure select
1.5
0
Oil valve proof of closure
1.6
0
Second airflow switch (primary air) enable
1.7
0
Safety time configuration set
1.8
0
Force Mode Input
2.0
0
Drive 0 name
not used
2.1
2
Drive 1 name
gas servo motor
2.2
3
Drive 2 name
oil servo motor
2.3
10
Drive 3 name
air servo motor
2.4
11
Drive 4 name
VSD drive
2.5
0
Drive 5 name
2.6
0
Drive 6 name
2.7
0
Drive 7 name
2.8
0
Drive 8 name
2.9
0
Drive 9 name
3.0
0
Drive 0 serial number
not used
3.1
xxxx
Drive 1 serial number - Gas Servo
1st 4 Digits of Ser No
3.2
xxxx
Drive 2 serial number - Oil Servo
1st 4 Digits of Ser No
3.3
xxxx
Drive 3 serial number - Air Servo
1st 4 Digits of Ser No
Found on side of servo motor
3.4
VSD1
Drive 4 serial number
3.5
0
Drive 5 serial number
3.6
0
Drive 6 serial number
3.7
0
Drive 7 serial number
3.8
0
Drive 8 serial number
3.9
0
Drive 9 serial number
4.0
0
Drive 0 profile assignment
not used
4.1
1
Drive 1 profile assignment
profile 1
4.2
2
Drive 2 profile assignment
profile 2
4.3
3
Drive 3 profile assignment
profiles 1 + 2 = 3
4.4
3
Drive 4 profile assignment
profiles 1 + 2 = 3
