Operating Instructions For TD/TAD4 Dual Fuel Burner
June 13 59 of 165 TD/TAD4 Manual Rev 4
4.5
0
Drive 5 profile assignment
4.6
0
Drive 6 profile assignment
4.7
0
Drive 7 profile assignment
4.8
0
Drive 8 profile assignment
4.9
0
Drive 9 profile assignment
5.0
0
Drive 0 rotation
0 = anti-clockwise / 1 = clockwise
5.1
0
Drive 1 rotation
0 = anti-clockwise / 1 = clockwise
5.2
0
Drive 2 rotation
0 = anti-clockwise / 1 = clockwise
5.3
0
Drive 3 rotation
0 = anti-clockwise / 1 = clockwise
5.4
0
Drive 4 rotation
0 = anti-clockwise / 1 = clockwise
5.5
0
Drive 5 rotation
0 = anti-clockwise / 1 = clockwise
5.6
0
Drive 6 rotation
0 = anti-clockwise / 1 = clockwise
5.7
0
Drive 7 rotation
0 = anti-clockwise / 1 = clockwise
5.8
0
Drive 8 rotation
0 = anti-clockwise / 1 = clockwise
5.9
0
Drive 9 rotation
0 = anti-clockwise / 1 = clockwise
6.1
1
Fuel train for profile 1
gas
6.2
1
Fuel train for profile 2
oil
6.3
0
Fuel train for profile 3
6.4
0
Fuel train for profile 4
7.0
0
Fan on early time
7.1
15
Air Proving time
7.2
30
Pre-purge time
Do not reduce this timing
7.3
1
Pre-ignition time
Do not extend this timing
7.4
3
Pilot ignition time
Do not extend this timing
7.5
3
Pilot hold time
Do not extend this timing
7.6
3
Main ignition time
Do not extend this timing
7.7
3
Ignition hold time
Do not extend this timing
7.8
5
Low fire hold time
Do not extend this timing
7.9
30
Post purge time
Do not reduce this timing
8.0
0
Ignition spark output check
8.1
1
Flame failure response time
8.2
0
Extend false flame response time
9.0
0
Inverter control accuracy
0 = low / 1 = high
9.1
1
Inverter error tolerance
0 = low / 1 = high
9.2
100
Inverter closed loop gain
9.3
30
Inverter stop time
9.4
30
Inverter acceleration time
9.5
0
VSD1 speed encoder scaler
9.6
0
VSD2 speed encoder scaler
9.7
0
Low speed cup limit
9.8
0
Oil warning speed
10.0
0
Gas pressure sensor select
1 valve proving via sensor,
0 valve proving via pressure
switches
10.1
0
Gas pressure sensor span
10.2
70
Gas pressure nominal
Parameters 10.2, 10.5 and 10.6 will
give a valve proving time of approx
40secs. This is an optimised set of
figures do not alter
10.3
0
Gas pressure low limit
10.4
0
Gas pressure high limit
10.5
1
Test volume
