Operating Instructions For TD/TAD4 Dual Fuel Burner
June 13 60 of 165 TD/TAD4 Manual Rev 4
10.6
7.5
Maximum permissible leakage rate
10.7
0
Vent valve select
10.8
1
Valve proving select
1 – VPS enabled, DO NOT DISABLE
10.9
3
VPS Power Time
12.0
0
Photocell / IR flame detection select
12.1
0
Pilot flame threshold photocell
12.2
0
Main flame threshold photocell
12.3
0
Centre frequency photocell
12.4
0
Frequency pass ban photocell
13.0
x
UV/Ionisation flame detection
1=non-shuttered/2=shuttered
13.1
x
Pilot flame threshold
non-shuttered = 20, shuttered = 10
13.2
20
Main flame threshold
14.0
6
Primary fault relay
14.1
0
Limit relay
14.2
0
Oxygen + fuel temperature limit relay
14.3
0
Permanent gas pilot select
14.4
1
Pilot with/without main valve select
0 = without / 1 = with
14.5
1
Direct ignition on oil
14.6
0
Spark termination
14.7
1
Oil pump relay function
1 = light oil / 2 = heavy oil
14.8
0
Extended oil pilot
15.0
2
Modulation input sensor type
2 = 4-20mA
15.1
x
Modulation input decimal places
0 = temp / 1 = pressure
15.2
0
Modulation input zero value
15.3
xx
Modulation input span value
default: temp = 150, pressure = 16.0
15.4
x
Set-point display units
1 = bar / 3 = deg c
15.5
0
Boiler high safety limit
15.6
20
Modulation time
15.7
0
Bumpless transfer
15.8
1
Low fire before off
0 = no / 1 = yes
16.1
0
Go back to pilot
16.2
0
Allow profile swap online
16.3
011
HV input 12 alarm/lockout function
Boiler high limit stat, on PE7
16.4
012
HV input 13 alarm/lockout function
Fan trip, on PE8
16.5
xx
HV input 12 display message
11 – high temp, 13 – high pressure,
on PE7
16.6
17
HV input 13 display message
Fan interlock, on PE8
17.1
0
Relay 1 output function
(display unit) PR1,PR2,PR3
17.2
20
Relay 2 output function
(display unit) PR5,PR6,PR7
17.3
19
Relay 3 output function
(display unit) PR7,PR8,PR9
17.4
20
Relay 4 output function
(controller) PD6,PD7,PD8
17.5
19
Relay 5 output function
(controller) PD4,PD5,PD6
17.6
0
Relay 6 output function
(controller) PD1,PD2,PD3
17.7
26
Relay 7 output function
(26 = VSD1 start circuit) PZ17-PZ18
17.8
0
Relay 8 output function
PZ15-PZ16
18.1
0
LV input 1 function
PB9-PB10
18.2
0
LV input 2 function
PB9-PB11
18.3
0
LV input 3 function
PB9-PB12
18.4
0
LV input 4 function
PB9-PB13
18.5
22
LV input 5 function
Low Gas Pressure PB14-PB15
18.6
21
LV input 6 function
High Gas Pressure PB14-PB16
