Operating Instructions For TD/TAD4 Dual Fuel Burner
June 13 61 of 165 TD/TAD4 Manual Rev 4
18.7
0
LV input 7 function
PB14-PB17
18.8
0
LV input 8 function
PB5-PB6
18.9
0
LV input 9 function
PB5-PB7
19.1
0
LV input 1 message
PB9-PB10
19.2
0
LV input 2 message
PB9-PB11
19.3
0
LV input 3 message
PB9-PB12
19.4
0
LV input 4 message
PB9-PB13
19.5
5
LV input 5 message
Low Gas PB14-PB15
19.6
4
LV input 6 message
High Gas PB14-PB16
19.7
0
LV input 7 message
PB14-PB17
19.8
0
LV input 8 message
PB5-PB6
19.9
0
LV input 9 message
PB5-PB7
20.0
0
Set-point select input
1-7 or 12-13
20.1
0
Boiler shutdown input
1-7 or 12-13
20.2
0
Low fire hold input
1-7 or 12-13
20.3
0
Oxygen trim disable input
1-7 or 12-13
20.4
0
Ignition wait input
1-7 or 12-13
20.5
0
Purge hold input
1-7 or 12-13
20.6
0
Purge time start input
1-7 or 12-13
20.7
0
Analogue input 5 option
aux mod input
20.8
0
Lead boiler select
1-7 or 12-13
21.0
0
Set-point 1 enable
21.1
x
Set-point 1 control value
default: temp = 80, pressure = 8.0
21.2
0.5
Set-point 1 proportional value
default: temp = 1, pressure = 0.5
21.3
1
Set-point 1 integral time
21.4
0
Set-point 1 derivative time
21.5
2
Set-point 1 control limit type
Deviation
21.6
0.5
Set-point 1 low limit control value
default: temp = 10, pressure = 0.5
Burner On 0.5 below SP
21.7
0.5
Set-point 1 high limit control value
default: temp = 10, pressure = 0.5
Burner Off 0.5 above SP
21.8
0
Remote set-point 1 zero (4mA) value
21.9
0
Remote set-point 1 span (20mA) value
22.0
0
Set-point 2 enable
22.1
0
Set-point 2 control value
22.2
0
Set-point 2 proportional value
22.3
0
Set-point 2 integral time
22.4
0
Set-point 2 derivative time
22.5
0
Set-point 2 control limit type
22.6
0
Set-point 2 low limit control value
22.7
0
Set-point 2 high limit control value
22.8
0
Mod Max Enable Input
22.9
0
Mod Max Value
23.0
0
Warming enable
23.1
0
Warming limit
23.2
0
Warming time
24.0
0
Number of sequence lag boilers
enables into sequencing
24.1
0
1st lag boiler address
24.2
0
2nd lag boiler address
24.3
0
3rd lag boiler address
24.5
0
Lead assign type
24.6
0
Lag on rate
