Operating Instructions For TD/TAD4 Dual Fuel Burner
June 13 62 of 165 TD/TAD4 Manual Rev 4
24.7
0
Lag on delay
24.8
0
Lag off rate
24.9
0
Lag off delay
29.0
0
Analogue output 1 function
VSD1 overrides if selected
29.1
0
Analogue output 1 zero (4mA) value
29.2
0
Analogue output 1 span (20mA) value
29.3
0
Analogue output 2 function
VSD2 overrides if selected
29.4
0
Analogue output 2 zero (4mA) value
29.5
0
Analogue output 2 span (20mA) value
29.6
0
Analogue output 3 function
29.7
0
Analogue output 3 zero (4mA) value
29.8
0
Analogue output 3 span (20mA) value
30.0
0
Oxygen probe interface serial number
30.1
0
Oxygen probe calibration offset value
30.2
0
Oxygen probe calibration gain value
30.3
0
Oxygen probe calibration gas
concentration
30.4
0
Flue & inlet temp sensor units
30.5
0
Oxygen input function
30.6
0
Oxygen probe calibrate enable
30.7
0
Boiler transport delay
30.8
0
Reset oxygen trim profile
30.9
0
Automatic trim commissioning
31.0
0
Limit modulation range
31.1-
31.4
0
Trim type for profiles
32.0
0
Trim limit default
32.1-
32.4
0
Trim limits
33.1-
33.4
0
Trim integral gain
34.0
0
Trim proportional gain default
34.1-
34.4
0
Trim proportional gain
35.0
0
Inlet temp sensor serial number
35.1-
35.4
0
Hydrocarbon ratios for each fuel
respectively
35.5-
35.8
0
Calorific values of fuels / profiles 1-4
respectively
35.9
0
Boiler radiated heat loss
36.0
0
Flue temperature alarm select
36.1-
36.4
0
Flue temperature low alarm value
37.1-
37.4
0
Flue temperature high alarm value
38.0
0
Oxygen alarm select
38.1-
38.4
0
Oxygen low alarm value at low fire
39.1-
39.4
0
Oxygen low alarm value at high fire
40.1-
40.4
0
Oxygen high alarm at low fire
41.1-
41.3
0
Oxygen high alarm at high fire
42.0
0
Second oxygen probe select
