Operating Instructions For TD/TAD4 Dual Fuel Burner
June 13 88 of 165 TD/TAD4 Manual Rev 4
30
1
JACKING SCREW
FASHEX00150
31
2
OIL ELECTRODE
IGELEC00110
32
1
OIL TUBE SUPPORT SPIDER
GA12370
33
4
SPLIT ELECTRODE BUSH
GA8264
34
1
ART1400 BURNER GUN
GA21876
35
2
POSITIONAL ELBOW 10-4L 10mm
COMPAD00550
36
12
1/4"BSP DOWTY 'BONDED' SEAL
SEADOW00105
37
4
1/4" BSP YORKSHIRE FTG. BRASS PLUG
YORFIT00510
38
2
SWIVEL ELBOW 10mm MSE 10-4 L
COMPAD00505
39
1
TWIN PORT SANDWICH BLOCK (INSIDE)
GA9178A
40
2
SANDWICH BLOCK INNER O-RING
ORINGS00180
41
1
SANDWICH BLOCK OUTER O-RING
0RINGS01025
42
1
TWIN PORT SANDWICH BLOCK (OUTSIDE)
GA9178B
43
1
MALE STUD COUPLING 10mm MMC 10-4 L
COMPAD00485
44
5
STANDPIPE ADAPTOR 10mm MSA 10-4 L
COMPAD00535
45
3
EQUAL TEES 10mm 10 L
COMPAD00520
46
4
MOTOR HANGER PLATE SPACER
GA7961
47
1
VARIOTRONIC OIL METERING VALVE ASSEMBLY
GA16090
48
2
1/4" MINI BALL VALVE
VALOIL00110
49
2
M5 COPPER WASHER
COPWAS00025
50
2
0 - 600 PSI PRESSURE GUAGE
PRESGA00100
51
3
MALE STUD COUPLING 10mm X 3/8" MMC 10-6 L
COMPAD00490
52
4
3/8"BSP DOWTY 'BONDED' SEAL
SEADOW00100
53
2
PRESSURE SWITCH ADAPTOR
BANMAN00170
54
2
1/4" COPPER WASHER
COPWAS00075
55
1
SAUTER HIGH OIL PRESSURE SWITCH
BAILEY HIGH OIL PRESSURE SWITCH
PRESWI00570
PRESWI00700
56
1
BRIDGE HANDLE
CONTOL02285
57
2
STANDPIPE ADAPTORS 10mm MSA 10-8 L
COMAD00545
58
12
1/2"BSP DOWTY 'BONDED' SEAL
SEADOW00110
59
1
1/2" LUCIFER OIL SOLENOID VALVE
SOLOIL00360
60
3
MALE STUD COUPLING 10mm x 1/2" MMC 10-8 L
COMPAD00495
61
1
3/8" BSP BANJO BOLT #7 x 70
GA10382
62
1
1/2" BSP BANJO BOLT #4 x 72
GA10143
63
1
MANIFOLD No. 4 WITH VALVE CLUSTER
GA16780
64
1
COPPER WASHER 3/8"
COPWAS00100
65
1
COPPER WASHER 1/2"
COPWAS00110
66
1
1"BSP 'HEAVYWEIGHT' BARREL NIPPLE
PIPNIP01340
67
1
DH1-1-CLOCKWISE ROTATION
DH1-2-CLOCKWISE ROTATION
DH1-1-ANTI-CLOCKWISE ROTATION
DH1-1-ANTI-CLOCKWISE
PUMDUN01012
PUMDUN01010
PUMDUN01025
PUMDUN01020
68
1
POSITIONAL ELBOW 3/4" x 1/2"
CONELB00125
69
2
OIL SOL VALVE LUCIFER 1/2" N/C
SOLOIL00240
70
1
OIL MANIFOLD No. 1
GA16777
71
2
1/2" BSP BANJO BOLT #3 x 54
GA10125
72
1
MOUNTING BRACKET FOR VALVE CLUSTER FITTET TO DH-1
GA10190
73
1
D.90 MOTOR BELL HOUSING
GA05900
74
1
PUMP COUPLING ASSEMBLY
PUMZCP00665
