Operating Instructions For TD/TAD4 Dual Fuel Burner
June 13 92 of 165 TD/TAD4 Manual Rev 4
ITEM
QTY.
DESCRIPTION
DWG/PART No.
1
1
TD415-420 LOW NOx COMBUSTION HEAD ASSEMBLY
TD415-420 COMBUSTION HEAD ASSEMBLY
GA23555
GA23558
2
1
T4 VANE CASTING
GA08715
3
1
T410 FAN IMPELLOR (WHITE)
T415 FAN IMPELLOR (BLUE)
T420 FAN IMPELLOR (BLACK
GA8765
GA8764
GA8763
4
1
T4 BODY (FAN HALF)
GA08716
5
1
EYEBOLT T4 16MM 58mm O/D x32mm I/D
EYEBLT00100
7
1
TD420 15KW FAN MOTOR
MOTORF01250
8
1
ANODISE OUTER SHUTTER TD420
GA17290
9
1
ANODISE INNER SHUTTER TD420
GA17210
10A
1
SILENCER FOR TD420
GA08893
10B
1
T420 SNORKEL SILENCER WITH CHAMFERED CORNERS
GA21504
10C
1
SNORKEL SILENCER MESH
GA16838
11
1
SPACER FOR MOD PLATE
GA07961
12
2
ROD END BEARING
BEAROS00250
13
1
SERVO MOTOR LINKARM
GA18765
14
1
MOD PLATE
GA17188
15
1
ETC6027 CANBUS SERVO MOTOR 12Nm
ETCRAT00745
17
1
542 ELECTRICAL ENCLOSURE
552 ELECTRICAL ENCLOSURE
667 ELECTRICAL ENCLOSURE
GA10724
GA10720
GA12409
18
1
DOOR FOR 542 ELECTRICAL ENCLOSURE
DOOR FOR 552 ELECTRICAL ENCLOSURE
DOOR FOR 667 ELECTRICAL ENCLOSURE
GA10726
GA10722
GA10723
19
1
SIDE ENTRY GASKET
GA08990
20
1
GAS TRAIN FLANGE 80
GA07099
21
1
BUTTERFLY VALVE 80mm
GA17187
22A
1
T4 UNIBLOC SIDE ENTRY ASSEMBLY DN65
T4 UNIBLOC SIDE ENTRY ASSEMBLY DN80
T4 UNIBLOC SIDE ENTRY ASSEMBLY DN100
GA23518A
GA23518B
GA23518C
22B
1
T4 VGD40 SIDE ENTRY ASSEMBLY DN65
T4 VGD40 SIDE ENTRY ASSEMBLY DN80
T4 VGD40 SIDE ENTRY ASSEMBLY DN100
GA23529A
GA23529B
GA23529C
23
1
MALE STUD COUPLING 10MM x 3/8" BSP
COMPAD00490
24
1
10mm BUNDI TUBE
BUNDIT00145
25
1
PRESSURE SWITCH
PRESWI00246
26
1
INNER NYLON ROLLER
GA5761A
27
1
OUTER NYLON ROLLER
GA5761B
28
1
Y TYPE MOUNTING GASKET
GA11742
29
1
QRA2 UV CELL WITH BRACKET
12041
30
1
JACKING SCREW
FASHEX00150
31
1
BRIDGE HANDLE
CONTOL02285
32
1
BRIDGE HANDLE
CONTOL02285
33
1
FLAME PLATE
GA10613
34
2
IGNITION ELECTRODE
IGELEC00110
35
4
OIL TUBE SUPPORT SPIDER
GA8264
36
1
SHELL HEAD FOR OIL BURNERS
GA8233A
37
1
ART1400 OIL BURNER GUN
GA21876
38
2
POSITIONAL ELBOW 10-4L
COMPAD00550
