Duplo DC-F 1 User Manual

- 12 -
1. Part Names and Their Functions
●Overall appearance (DC-F1)
No. Name Function
1 Control panel Displays operations and statuses.
2 Lock lever Use this to remove the paper jam.
3
Skew adjust knob
Adjusts horizontal fold skew.
4 Exited paper board Paper without folds is exited on this board.
5 Power switch
Press the ‘I’ side on the power switch to turn the power ON and
press the ‘○’ side to turn it OFF.
6 D-sub connector(9p) Use this to connect communication cable.
7 Inlet
Insert the female side plug on the provided power cord plug
here.
8 Top cover Open this to remove the paper jam.
9 D-sub connector(9p)
Connects the DC-F1 and DC machine (DC-645/DC-615/
DC-445) with a communication cable.
9
8
1
4
2
5
6
7
3
