Duplo DC-F 1

- 34 -
JOB 01 entry 4/7
Fold1
210.0mm
(42.5-377.5)
JOB 01 entry 4/7
Fold1
136.0mm
(42.5-335.0)
JOB 01 entry 5/7
Fold2
278.0mm
(178.5-377.5)
②Enter the dimension of Fold 1 using the NUMBER
keys and then press the SET key.
Right illustration: When ‘210.0mm’ is entered.
● C-fold
①Select ‘C-fold’ using the CURSOR keys (Right/Left)
and then press the SET key.
Right illustration: When ‘C-fold’ is selected.
②Enter the dimension of Fold 1 using the NUMBER
keys and then press the SET key.
Right illustration: When ‘136.0mm’ is entered.
③Enter the dimension of Fold 2 using the
NUMBER keys and then press the SET key.
Right illustration: When ‘278.0mm’ is entered.
● Z-fold
①Select ‘Z-fold’ using the CURSOR keys (Right/Left)
and then press the SET key.
Right illustration: When ‘Z-fold’ is selected.
JOB 01 entry 3/7
Set FOLD Type
JOB 01 entry 3/5
Sel FOLD Type
