- 86 -
1.Specifications
Model name DC-F1
Product type
Folder floor model
Fold types
①No fold (available only in DC mode)
②V fold ( in both directions)
③C fold
④Z fold
⑤Gate fold
⑥C-GATE (available only in DC mode)
⑦Double parallel fold
Feeding
No feeding mechanism
Infeed roller takes paper exited from the upstream unit.
* When connecting with DC-645/615: DC-SC1 is required.
* When connecting with DC-445: can be directly connected.
Infeed paper size No fold: Width 48mm - 370mm Length 85mm - 650mm
1-fold: Width 48mm - 370mm Length170mm - 650mm
2-fold: Width 48mm - 370mm Length170mm - 650mm
3-fold: Width 48mm - 370mm Length170mm - 650mm
Paper size depends on that of ejected paper from upstream unit.
Finished paper size No fold: Width 48mm - 370mm Length85mm - 650mm
1-fold : Width 48mm - 370mm Length85mm - (650mm-42.5mm)
2-fold : Width 48mm - 370mm Length85mm – (650mm-42.5mmx2)
Paper size depends on that of ejected paper from upstream unit.
Paper weight Bond paper: MIN:110gsm MAX:350gsm
Coated paper: MIN:110gsm MAX:350gsm
Laminated paper: within above range of weight including the
lamination
*The maximum paper weight for double parallel fold is 230gsm .
Paper type Bond, coated, laminated
Minimum finishing
size
Width 48mm x Length 85mm
(When using DC-CC1: Width 85mm x Length 85mm)
Speed 50 sheets / min.
A4（Width 210mm x Length 297mm）+ 1 center crease Æ 1-fold using
knife 1.
* The speed varies depending on the upstream unit connected.
①
To Next Page
