Note: In the interest of upgrading our products, specification and other data given in this manual are
subject to change without prior to notice.
Mode name DC-SC1
Product type Sheet conveyer, floor model
Feeding
No feeding mechanism
Takes up sheet exited from the upstream unit with conveying roller.
Infeed paper size No fold: Width 48mm - 370mm Length 85mm - 650mm
1-fold: Width 48mm - 370mm Length170mm - 650mm
2-fold: Width 48mm - 370mm Length170mm - 650mm
(Paper size depends on that of ejected paper ejected from upstream unit.)
Paper weight Bond MIN:110gsm MAX:350gsm
Coated MIN:110gsm MAX:350gsm
Laminated Within the above range of weight including lamination
Paper type Coated, bond, laminated
Minimum finished size Width 48mm x Length 85mm
(when using DC-CC1: Width 48mm x Length 85mm)
Requirements When cutting multiple-up documents on DC-645/615 connected,
* Slit gutter between each sheet on 1 document must be 5mm or more.
* Cut gutter between each sheet on 1 document must be 4mm or more.
Speed Depending on the speed of DC-F1.
Outfeed Convey sheet into feed rollers of DC-F1 with exit roller.
Power supply Supplied by DC-F1.
Dimension 550mm (W) x 610 mm (D) x 1070 mm (H)
The height depends on the upstream DC unit and downstream DC-F1.
Weight Approx. 46kg
Operating
temperature/humidity
10℃ - 30℃ 40％ - 70％（no condensation）
Storing
temperature/humidity
5℃ - 35℃ 20％ - 70％（no condensation, no salinity）
