30
12. CONNECTING THE DOWNSTREAM UNIT
7
Press the key to return to the
standby screen.
Press the key until the standby screen
is displayed.
5
Enter the length or width using the
numerical keys.
If any previously registered size of
paper length or width is remaining,
press the
key to clear to " 0 "
first before entering the new num-
ber.
The length and width ranges which can
be registered differ according to the bind-
ing method.
• Saddle stapling / folding
Length: 200 to 450 mm
Width: 200 to 320 mm
• Side stapling
Length: 139 to 231 mm
Width: 200 to 320 mm
• Corner stapling
A4 size ( Length: 210 mm Width: 297 mm )
6
Press the key and register the
value entered at step 5.
Note Values out of the specified range
will not be registered even if en-
tered. If such values are entered,
the display will return to the previ-
ous value. Enter values within the
specified range.
To redo the setting, press the
key and
register the value entered at step 5.
To Next Page
