Duplo DUPRINTER DP-440 - Page 261

263
c HELP Mode Function and Operation Procedures
chap.7
HELP-043
Spec setting
1111
H-43,H-44
(1) Adjustment / specification settingHELP mode
H-43
0100
0101
0101
0101
0101
0110
0110
0110
H-44
1011
1000
1001
1010
1011
1000
1001
1010
Lank
1
2
3
4
5
6
7
8
1822 - 1860
1861 - 1899
1900 - 1939
1940 - 1979
1980 - 2019
2020 - 2059
2060 - 2099
2100 - 2139
0110 1011 9 2140 - 2179
0111 1000 10 2180 - 2220
0111 1001 11 2221 - 2261
0111 1010 12 2262 - 2302
0111 1011 13 2303 - 2343
1000 1000 14 2344 - 2384
1000 1001 15 2385 - 2425
1000 1010 16 2426 - 2466
Lank
00
01
02
03
04
05
06
07
3825 - 3908
3909 - 3993
3994 - 4077
4078 - 4162
4163 - 4246
4247 - 4330
4331 - 4415
4416 - 4499
08 4500 - 4583
09 4584 - 4668
10 4669 - 4752
11 4753 - 4837
12 4838 - 4921
13 4922 - 5005
14 5006 - 5090
15 5091 - 5075
DP-440 / DP-340 DP-430 / DP-330
ePress the [=] key.
The correction amount will be memorized in the battery PCB unit's
EEPROM. During memorization,"SAVE" will be displayed.
Do not turn off the power before the "SAVE" display has disappeared.
1. Functions
(1) Thermal head resistance ranking setting
(1) Thermal head resistance ranking setting
¡During memorization:
IMPORTANT :
2. Operation procedure
Accessing HELP modes
a See page 213
qAccess HELP mode H-43, and press the PRINT key.
wUse the [0] and [1] numeric keys to enter a 4-place binary
value for the desired correction amount.
See the table below for 4-place binary values and the corresponding
correction amounts.
rPress the STOP key.
The HELP mode selection display will reappear.
A B C D
- SAVE -
