272
c HELP Mode Function and Operation Procedures
chap.7
2
Access HELP mode
H-57
, and press the
PRINT
key.
1 line scan time (H-57)
H-52, H-57
(1) Adjustment / specification settingHELP mode
H-52
00**
11**
**0*
**1*
***1
***0
***1
***0
H-57
0***
0***
1***
1***
Item
I / F auto / manual
setting
DP-10
test pattern
Setting
Manual
Auto(standard)
Standard
DP-10 test pattern only
1.6m sec / line
2.0m sec / line(standard)
3.2m sec / line
4.0m sec / line
0000 0000 Factory setting
1 line process /
scan time
ePress the [=] key.
The correction amount will be memorized in the battery PCB unit's
EEPROM. During memorization,"SAVE" will be displayed.
Do not turn off the power before the "SAVE" display has disappeared.
1. Functions
(1)
I/ F switch,DP-10 test pattern,1 line process time setting
¡Following items are indicated.
A : I/F switch(H-52)
B : DP-10 test pattern(H-52)
C,D : 1 line process time(H-52), 1 line scan time(H-57)
(1) I/ F switch,DP-10 test pattern,1 line process time setting
¡During memorization:
IMPORTANT :
2. Operation procedure
Accessing HELP modes
a See page 213
qAccess HELP mode H-52, and press the PRINT key.
HELP-052
Spec setting
1111
wUse the [0] and [1] numeric keys to enter a 4-place binary
value for the desired correction amount.
See the table below for 4-place binary values and the corresponding
correction amounts.
a To exit the HELP mode
: Turn the power switch OFF.
a
To access another HELP mode
:
Enter the desired mode number
using the numeric keys.
rPress the STOP key.
The HELP mode selection display will reappear.
A B C D
- SAVE -
HELP-057
Spec setting
1111
A B C D
