277
c HELP Mode Function and Operation Procedures
chap.7
H-59
(1) Adjustment / specification settingHELP mode
ePress the [=] key.
The correction amount will be memorized in the battery PCB unit's
EEPROM. During memorization,"SAVE" will be displayed.
Do not turn off the power before the "SAVE" display has disappeared.
1. Functions
(1)
"Out of ink" count change,Fine start mode ON/OFF setting
¡Following items are indicated.
A : ( Not used )
B : ( Not used )
C : "Out of ink" count change
D : Fine start mode ON/OFF (factory check)
(1) "Out of ink" count change,Fine start mode ON/OFF setting
¡During memorization:
IMPORTANT :
2. Operation procedure
Accessing HELP modes
a See page 213
qAccess HELP mode H-59, and press the PRINT key.
HELP-059
Spec setting
1111
wUse the [0] and [1] numeric keys to enter a 4-place binary
value for the desired correction amount.
See the table below for 4-place binary values and the corresponding
correction amounts.
a To exit the HELP mode
: Turn the power switch OFF.
a
To access another HELP mode
:
Enter the desired mode number
using the numeric keys.
rPress the STOP key.
The HELP mode selection display will reappear.
A B C D
- SAVE -
Display Item Setting
0
***
1
***
*
0
**
Not used
*
1
**
**
0
*
Changing of out-of-ink count.
Display of out-of-ink count
Changing of count value
Standard (20 revolutions at speed 3)
**
1
*
Treble (60 revolutions at speed 3)
***
0
Dis/enabling of Fine Start Mode
Enabled ((activated by HELP60/opera-
tion panel settings)
***
1
Disabled (enforced deactivation)
0 0 1 0
Factory setting
Not used
Modes H-57( refer to H-52). Modes H-58 is not used.
