DURKOPP ADLER 827 User Manual

10.2 Lubrication
Caution: danger of injury
Oil can cause skin eruptions.
Avoid protracted contact with the skin.
In the event of contact, thoroughly wash the affected area.
CAUTION:
The handling and disposal of mineral oils is subject to legal regulation.
Deliver used oil to an authorised collection point.
Protect your environment.
Take care not to spill oil.
To lubricate the special sewing machine use only DA 10 lubricating oil
or an equivalent oil of the following specification:
–
Viscosity at 40° C: 10 mm²/s
–
Flashpoint: 150° C
DA 10 is available from DÜRKOPP ADLER AG retail outlets under the
following part numbers:
250-ml container: 9047 000011
1-liter container: 9047 000012
2-liter container: 9047 000013
5-liter container: 9047 000014
Maintenance work Explanation Operating
to be carried out hours
Lubrication of the machine
head
The machine head is fitted with a central
oil-wick lubrication system.
The bearings are supplied out of oil
res ervoir 1.
- The oil level must not fall below the
marking line 3 (MIN) of the oil reservoir.
If the oil level falls below the marking line
3, the oil reservoir will be lit (only
the CLASSIC version).
- Fill in oil through the bore hole 2 up to the
marking line “Max”.
8
33
1
2
3
10.2 Lubrication
Caution: danger of injury
Oil can cause skin eruptions.
Avoid protracted contact with the skin.
In the event of contact, thoroughly wash the affected area.
CAUTION:
The handling and disposal of mineral oils is subject to legal regulation.
Deliver used oil to an authorised collection point.
Protect your environment.
Take care not to spill oil.
To lubricate the special sewing machine use only DA 10 lubricating oil
or an equivalent oil of the following specification:
–
Viscosity at 40° C: 10 mm²/s
–
Flashpoint: 150° C
DA 10 is available from DÜRKOPP ADLER AG retail outlets under the
following part numbers:
250-ml container: 9047 000011
1-liter container: 9047 000012
2-liter container: 9047 000013
5-liter container: 9047 000014
Maintenance work Explanation Operating
to be carried out hours
Lubrication of the machine
head
The machine head is fitted with a central
oil-wick lubrication system.
The bearings are supplied out of oil
res ervoir 1.
- The oil level must not fall below the
marking line 3 (MIN) of the oil reservoir.
If the oil level falls below the marking line
3, the oil reservoir will be lit (only
the CLASSIC version).
- Fill in oil through the bore hole 2 up to the
marking line “Max”.
8
33
1
2
3
10.2 Lubrication
Caution: danger of injury
Oil can cause skin eruptions.
Avoid protracted contact with the skin.
In the event of contact, thoroughly wash the affected area.
CAUTION:
The handling and disposal of mineral oils is subject to legal regulation.
Deliver used oil to an authorised collection point.
Protect your environment.
Take care not to spill oil.
To lubricate the special sewing machine use only DA 10 lubricating oil
or an equivalent oil of the following specification:
–
Viscosity at 40° C: 10 mm²/s
–
Flashpoint: 150° C
DA 10 is available from DÜRKOPP ADLER AG retail outlets under the
following part numbers:
250-ml container: 9047 000011
1-liter container: 9047 000012
2-liter container: 9047 000013
5-liter container: 9047 000014
Maintenance work Explanation Operating
to be carried out hours
Lubrication of the machine
head
The machine head is fitted with a central
oil-wick lubrication system.
The bearings are supplied out of oil
res ervoir 1.
- The oil level must not fall below the
marking line 3 (MIN) of the oil reservoir.
If the oil level falls below the marking line
3, the oil reservoir will be lit (only
the CLASSIC version).
- Fill in oil through the bore hole 2 up to the
marking line “Max”.
8
33
1
2
3
10.2 Lubrication
Caution: danger of injury
Oil can cause skin eruptions.
Avoid protracted contact with the skin.
In the event of contact, thoroughly wash the affected area.
CAUTION:
The handling and disposal of mineral oils is subject to legal regulation.
Deliver used oil to an authorised collection point.
Protect your environment.
Take care not to spill oil.
To lubricate the special sewing machine use only DA 10 lubricating oil
or an equivalent oil of the following specification:
–
Viscosity at 40° C: 10 mm²/s
–
Flashpoint: 150° C
DA 10 is available from DÜRKOPP ADLER AG retail outlets under the
following part numbers:
250-ml container: 9047 000011
1-liter container: 9047 000012
2-liter container: 9047 000013
5-liter container: 9047 000014
Maintenance work Explanation Operating
to be carried out hours
Lubrication of the machine
head
The machine head is fitted with a central
oil-wick lubrication system.
The bearings are supplied out of oil
res ervoir 1.
- The oil level must not fall below the
marking line 3 (MIN) of the oil reservoir.
If the oil level falls below the marking line
3, the oil reservoir will be lit (only
the CLASSIC version).
- Fill in oil through the bore hole 2 up to the
marking line “Max”.
8
33
1
2
3

DURKOPP ADLER 827 Specifications

General

Brand	DURKOPP ADLER
Model	827
Category	Sewing Machine
Language	English
