4.4
Setting
the
pedal
–
Adjust
the
side
position
of
the
pedal
(1)
so
that
its
center
lies
on
the
needle
axis.
–
Adjust
the
draw
rod
(2)
so
that
the
foot
axis
is
perpendicular
to
the
pedal
surface.
Caution!
Risk
of
injury!
Failure
to
keep
the
determined
pedal
position
c
an
cause
damage
to
the
operator
’s
locomotion
system.
11
GB
2
1
2
90°
3
46
48
