Roller presser folding
–
Lift the roller presser with the hand lever.
–
Lift the roller presser by pressing in the signed direction.
Caution! Risk of injury!
Roller presser folding to be done at main switch off and standing
motor.
6.9 Sewing-foot pressure
–
Regulate the roller presser pressure with the s etting wheel (1).
–
To inc rea se t he r oll er p res se r pr ess ure = turn the setting wheel (1)
clockwise.
To decre ase the rol ler presser pressure = turn the setting wheel (1)
anti-clockwise.
–
The roller pressure is to be as small as possible, but strong enough
that the roller presser is not lifted by the needle friction in the
material during the upward movement and that the feeding is
reliable.
–
The maximum roller presser pressure is 100N in the machine
equipped with electric magnets, and in the machine with the
pneumatic cylinders 160N.
17
GB
1
+
