6.1.3 Setting machine-specific parameters
6.1.3.1 DC1600/DA82GA drive
The value of the following parameters must be
Parameter Orig. value New value Parameter description
000 2 1* Stitch number of initial bartack forwards
001 2 2* Stitch number of initial bartack backwards
002 2 2* Stitch number of end bartack backwards
003 5 3* Stitch number of end bartack forwards
111 - - Max. sewing speed
116 150 180* Speed of thread trimming
140 1 2* Needle up/down
171-1E 160 164 225° on hand wheel
171-1A 210 214
171-2E 440 440 65° on hand wheel
171-2A 510 510
182 OFF ON 45° on hand wheel
190 450 190 Angular length of trimming switching on
192 210 190 Angular lag of tensioner magnet switching on
196 0 2* Foot connection with tensioner switching off after
trimming
203 200 350 Time of foot magnet full current
282 0 1* Machine operation blocking at opened contact
* After the master-reset those parameter values must be set again.
6.1.3.2 VD552KV/6F82FA drive
Parameter Original value New value Parameter description
000 2 1* Initial bartack stitch number forwards
001 2 2* Initial bartack stitch number backwards
002 2 2* End bartack stitch number backwards
003 5 3* End bartack stitch number forwards
111 - - Max. sewing speed
116 150 180* Trimming speed
140 1 2* Needle up/down
190 120 43 Angular length of trimming switching on
192 0 43 Angular lag of tensioner magnet switching on
196 0 2* Foot connection with tensioner switching off
after trimming
203 200 350 Foot magnet full current time
282 0 1* Operation blocking at opened contact
* After the master-reset those parameter values must be set again.
