GSC400 Specifications
VDC Rating 12/24 VDC
Standby Current
Consumption
50 mA @ 12 VDC
Operating Temp -40°C to +85°C (-40°F to +185°F)
LCD Operating
Temp***
-20
0
C to 70
0
C (-4
0
F to +158
0
F)
Function Selection Range
Speed Sensing Generator pickup
Magnetic pickup
0-300vac, 0-3600rpm
0-300vac, 0-3600rpm
Voltage Sensing Single phase,
Three phase,
Delta, Wye
Max 700vac, +/- 1%
Max 700vac, +/- 1%
Max 700vac, +/- 1%
Current Sensing* Enable/Disable Max 5A, +/- 2%
Frequency Sensing Enable/Disable 1 – 100 HZ
Engine Temp GND=Fail, Open=Fail 10-265°F, 10-265°C
Oil Pressure GND=Fail, Open=Fail 0-90 PSI, 0-90 Kpa
Oil Level GND=Fail, Open=Fail 0-90%
Fuel Level GND=Fail, Open=Fail 0-100%
Engine Logic Delay to start
Pre-heat
Crank
Rest Time
Mid Heat
Crank attempts
False restart
Post heat
Warm-up
Cooldown
Crank oil pressure
Crank Disconnect
0 – 60 seconds
0 – 60 seconds
3 – 60 seconds
1 – 60 seconds
0 – 60 seconds
1-60 tries
Enable, Disabled
0 – 60 seconds
0 – 600 seconds
0-600 seconds
0-90 KPa
100-2000 RPM
Analog Input Input 2 (Low Z, Gain = 1)
Input 3,4 (Low Z, Gain = 3)
Input 5,7 (High Z, Gain =3)
Input 6 (High Z, Gain = 1)
Gnd=Fail, Open=fail, 7mA Max
Note: On LS/LX controllers
Input 2 is High Z, Gain = 3 and
Input 6 has a gain of 3.
Digital Input Input A-D (Sw to Bat)
Input E-H (Sw to Gnd)
Bat=Fail, 7mA Max
Gnd=Fail, 7mA Max
Digital Output Output A-H
Extra Relay
200 mA Max
40A Max
Exerciser Enable, Disable 10-240 Minutes
Battery Recharge Enable, Disable 10-240 Minutes
Function
Selection
Range
Password 4-Digit 0-9
LCD Display 128x64 Graphic display, Backlit, 60° viewing angle
LED Display Red, Green, Yellow LED representation, Daytime Visible, 60° viewing angle
Programming Manual, Software, Field upgradeable
J1939 Interface Low emission capable
Relays** Replaceable 40A relays for Crank, Fuel, Extra output. 12 or 24VDC Coil
Dimensions W x H x D, 139 x 113 x 65 mm (5.47 x 4.45 x 2.56 in.)
Weight 0.45 Kg (1.0 Lb)
*Use of Industry Standard CT Required. ** 40A output at room temperature. *** The LCD
display will exhibit color and response time changes at high and low temperatures respectively
but will not be damaged as long as within Operating Temp.
