5.9.3 Event History Log
The GSC400 incorporates an event
history logging system. When engine
failures, events, or DTCs (Diagnostic
Trouble Codes – see section 5.13 on
page 40) occur, an entry is created in
the GSC400 Event History Log. See
Table 6 – Event Log Entries below for
the possible events that are stored.
A total of 100 entries can be recorded.
Entries may be viewed simply by scrolling up or down using the “UP” and “DOWN”
keys. In addition to the entry reason information, the associated date and time of the entry
will be displayed.
The 100 entries are subdivided into a maximum of 30 events, 40 failures, and 30 DTCs.
This prevents one type from flushing the other types from the log.
Simply scroll through the Failure
History Log by pressing the or
keys located on the GSC400.
The event history log can store up to
30 event, 30 DTCs, and 40 failures
entries. If these are exceeded the
entry is replaced with the newest
entry. The events, failures, and DTC entries are displayed together in the log in reverse
chronological order (i.e. newest entry first).
Upgrading the controller firmware to revision 2.00 from an earlier revision will cause the
history log to be reset.
