Page #79 background imageLoading...
Page #79 background image
79 of 105
The following table identifies all the wiring harnesses as part of the GSC400 controller:
Table 19 – GSC400 Wiring Harness Part List
Harness
Description
Stock Code Harness Length
Circuit Numbers
(Pins) Populated
2
AC Current
Sensing*
DWG1375R2-5 5 Feet 1, 2, 3
Digital Input* DWG1378R2-5 5 Feet All circuits
Analog Input* DWG1376R2-5 5 Feet 1, 2, 3, 4
J1939 DWG1373R3-5 5 Feet 1, 2, 3, 4
Digital Output DWG1377R2-5 5 Feet
4, 7, 8, 9
1
, 10, 11,
12
1
Modbus DWG1454R1.0 5 Feet
1, 2, 3
3
*The AC Current Sensing, Digital Input and Analog Input Harness can be purchased
together as a starter kit: Stock Code ACC0086. See section 12 on page 104 for the
drawing.
1
Circuits 9 and 12 are tied together. This disables the emergency stop input. For users
who desire this feature cut this wire.
2
See Figure 4 on page 15 for information on pin numbers.
3
This harness also provides power and ground for modbus devices via connections to
the GSC400 extra power and ground terminals.
9.2 GSC400 Programmer
The GSC400 programmer can be used to configure the GSC400 settings (instead of using
the front panel menu) and load new firmware (software for the GSC400 that gives it new
feature, performance improvements, or bug fixes).
Table 20 – GSC400 Programmer Part List
Programmer Description Stock Code
USB/Serial Programmer GSC400-PGMRB
