DynaGen GSC400 Series User Manual

69 of 105
1. Global –Everywhere
2. Crank – From start of delay-to-start to the end of
cranking
3. Run – RUN Mode only
4. Crank+Run – Combination of 2 and 3 above.
These settings are located at the bottom of the menu for each
input.
6.9 Battery Setup
The Battery menu allows the user to set the low and high battery warning and failure
levels. In addition, the generator can be made to automatically start when in the AUTO
state if the voltage drops below the Recharge Level.
The controller will display Low Voltage During Cranking on the screen if during
cranking the voltage drops below the Low Vol InCrank setting.
Note: When the generator is running, the battery voltage will equal the alternator
charging voltage. The actual open-circuit battery voltage may be lower than displayed.
6.9.1 Low Battery Recharge
The GSC400 can be setup to automatically run the generator if the battery voltage goes
below a certain point, the Recharge Level setting. The Charge Enable parameter must
be set to Enable to enable the low battery recharge feature. The ChargeDuration setting
controls the length of time the generator will run before shutting down.
Note that the GSC400 does not have the capability of charging the battery to a specified
voltage level.
