81 of 105
9.4 Engine Sending Units
Senders are required if display of engine parameters, warnings and failures are required.
Otherwise switches could be used if only failure indication and shutdown is required.
Table 22 – Senders Part List
Sender Description Stock Code Part # Description
Datcon – Oil Pressure (34 to 241
Ohms)
ACC0074
Datcon 102225-00 1/8” = 27
NPTF (Heavy duty version of
Datcon 2505-00)
Datcon – Temperature ( 7 to 491
Ohms), 1/8”
ACC0027
Datcon 02022-00 1/8”-27
NPTF
Datcon – Temperature, 3/8” ACC0098
DATCON - 02024-00 3/8" 18
NPTF
Datcon – Temperature, 1/2” ACC0099
DATCON - 02025-00 1/2" 14
NPTF
9.5 GSC400 replaceable 12/24VDC relays
The GSC400 controller is designed to operate in either 12 or 24 VDC battery start systems. When
operating in 12VDC systems the fuel, crank and extra relays need to be rated 12VDC coil. When
operating in 24VDC systems these relays need to be rated 24VDC coil. To maintain the UL
rating, the HASCO relays must be used.
Table 23 – Relay Part List
Relay Description Stock Code
Manufacturer’s Part
No.
12VDC AZETTLER RLY0029 AZ-973-1C-12DC
24VDC AZETTLER RLY0043 AZ-973-1C-24DC
12VDC HASCO RLY0053 CAR-1A-40-DC12S
24VDC HASCO RLY0054 CAR-1A-40-DC24S
