66 of 105
Warning (section 7.4) is activated.
Fuel In Basin Warning This turns on the digital output if the Low Fuel In Basin Warning
(section 6.2) is activated.
Voltage Regulator This allows the digital output to be controlled by the idle feature.
The idle feature also requires a digital input to be set to Idle Mode
(see section 6.8). See section 5.5 on page 25 for more information
on the Idle Mode feature.
Low Temperature Warning This turns on the digital output if the Low Engine Temperature
Warning (section 6.2) is activated.
Backlight This turns off the digital output if the LCD backlighting turns off.
The controller enters the sleep mode (section 5.3) when this
occurs.
Auxiliary Warning This turns on the output if the Auxiliary Warning Digital Input
(see Table 15 in section 6.8) is active.
Maintenance Timer This turns on the output if maintenance is required to be
performed on the engine/generator. See section 6.11.
System Ready This turns on the output if the controller is in the auto state with no
warnings (some warnings are ignored for this feature such as low
and high battery voltage).
Common Fault Output 1 This turns on the output if the Common Fault 1 feature is active.
See section 6.13 for more details.
Common Fault Output 2 This turns on the output if the Common Fault 2 feature is active.
See section 6.13 for more details.
Dummy Load This allows the digital output to be controlled by the Dummy Load
feature. See section 6.14 for more details.
High Fuel Level Warning This turns on the output if the High Fuel Level Warning digital
input in Table 15 on page 67 is active.
Current Latch This turns on the output if the Cur Warn Latch in the AC Current
menu (see Table 9 on page 46) is set to Enable and the High
Current Warning is active. The output can only be turned off by
the user. See section 6.4.3 on page 61 for more information.
Config Warn 1 This turns on the output if the Config Warn 1 digital input (Table
15 on page 67) is active.
Config Warn 2 This turns on the output if the Config Warn 2 digital input (Table
15 on page 67) is active.
Config Fail 1 This turns on the output if the Config Fail 1 digital input (Table 15
on page 67) is active.
Config Fail 2 This turns on the output if the Config Fail 2 digital input (Table 15
on page 67) is active.
6.7 Exerciser Setup
The GSC400 can be set to automatically start the engine/generator at regular intervals if
left in the AUTO state. This is controlled by the Exerciser Setup menu. The Exerciser
Enable should be set to Enabled if this feature is desired.
