SV-D700, SV-D1000 and SV-D1000T Operation
SkyView Classic Pilot’s User Guide – Revision Z 5-3
• The POWR/ECO widget will turn green and display “ECO mode” when the engine is running
economically. In this mode you will experience reduced fuel consumption.
• When the engine is off, the THRTL widget will show a green range to assist cold-start
scenarios. Note that both lane switches and start power must be on in order to display the
throttle position widget.
See your Rotax manual for more information.
SkyView can be configured to adjust the oil temperature and tachometer gauges for the Rotax
912 engine dynamically to reflect limitations that Rotax specifies for that engine. When this
behavior is turned on (per the SkyView System Installation Guide), the tachometer and oil
temperature behave in the following ways:
Tachometer for Rotax 912:
When OIL TEMP < 120° F, the TACHOMETER displays these ranges:
• 0-1400 and 4000-6000 RPM in RED.
• 1400-1800 and 2500-4000 RPM in YELLOW.
• 1800-2500 RPM in GREEN.
When OIL TEMP > 120° F, the TACHOMETER displays different ranges:
• 0-1400 and 5800-6000 RPM in RED.
• 1400-1800 and 5500-5800 RPM in YELLOW.
• 1800-5500 RPM in GREEN.
The alarm type for the tachometer is the “self-clearing” type.
Oil Temperature Gauge for Rotax 912:
When OIL TEMP < 190° F, the OIL TEMP gauge displays these ranges:
• 100-120 and 230-266° F in YELLOW.
• 120-190° F in GREEN if OIL TEMP has been above 190° F “more recently” than OIL
TEMP was below 120° F; otherwise 120-190° F is displayed in BLACK OUTLINED IN
WHITE.
• 190-230° F in GREEN.
• 266-280° F in RED.
When OIL TEMP is > 190° F, the OIL TEMP gauge will display different ranges:
• 100-120 and 230-266° F in YELLOW.
• 120-230° F in GREEN.
• 266-280° F in RED.
The alarm type for oil temperature is the “self-clearing type.
