8
8
8
8
C
C
C
C hapter
hapter
hapter
hapter 1
1
1
1 General
General
General
General Introduction
Introduction
Introduction
Introduction to
to
to
to xLogic
xLogic
xLogic
xLogic
Overview
Overview
Overview
Overview
xLogic SuperRelay is a universal logic module made by Easy.
xLogic SuperRelay, a compact, expandable CPU that can replace mini PLC, multiple timers,
relays and counters, Splitting the difference between a timing relay and a low-end PLC, Each
CPU houses a real-time clock and calendar , and supports optional expansion I/O modules to
enhance your control and monitoring applications . Data adjustments can be done via the
on-board keypad and LCD display, or with xLogic soft. It can be either DIN-rail or panel
mounted, depending upon the needs of your application, and it is available in 120V/240V ac as
well as 12V and 24V dc versions, and it is the ideal solution for relay replacement applications,
simple control applications such as building and parking lot lighting, managing automatic
lighting, access control, watering systems, pump control, or ventilation systems in factory, and
home automation and applications in which cost is a primary design issue.
Highligh
Highligh
Highligh
Highligh t
t
t
t features:
features:
features:
features:
4-lines, 10-character per line, backlight display.
Multiple value display and input via keypad and LCD display.
Keypanel programming feature ( optional )
Function Block Diagram
Standard Modbus RTU /ASCII communication protocol supported.
It
’
s optional for xLogic to act as slave or master in certain Modbus RTU communication
network.
CAN BUS protocol based expansion modules
Expandable up to 9 linked IO expansion modules reaching 162 I/O points in maximum
1 RS232 port and 2 RS485 port s built-in (merely applied to standard ELC-12 Series ) ; 1
RS232 port and 1 RS485 port built-in (merely applied to ELC-18 Series )
Optional Ethernet connectivity
SMS /GSM module for remote control, monitoring and alarm
Multiple channels analog inputs available with DC 0-10V signal ,PT100 signal& 0/4 … .20mA.
Default Real Time Clock (RTC)
Backup at Real Time Clock (RTC) at 25 ° C :72 hours(ELC-6&economy ELC-12);100
hours(Standard ELC-12&Upgraded ELC-18)
Two channel s high-speed counting (ELC-18 Series CPU :14KHz; Upgraded
ELC-18&ELC-12 Series CPU:60KHz )
Pre-configured standard functions, e.g. on/ off-delays, pulse relay and softkey
2 PWM channels (333Hz)
Retentive memory capability (Not applied to ELC-6&economic ELC-12)
RS232 communication download cable with photo-electricity isolation
USB communication download cable with photo-electricity isolation
Programmable capability up to 256 function blocks(ELC-18) ,512 function blocks(ELC-1 2 )
Mounting via modular 35mm DIN rail or screw fixed mounting plate
On-line monitor capability
Compact design
HMI(LCD) separate installation available,e.g. xLogic can be installed inside cabinet and HMI
mounted in it
’
s front panel
Datalogging
Low cost
