143

Data format instruction

F or the detail information about I,AI,Q,AQ, registers address of xLogic ,refer to the RTU protocol file.

4 .14

.14

.14 Data

Data

Data latching

latching

latching relay

relay

Short

Short description

description

This special function saves the process variable of an analog input to memory, and returns it at

the analog output.

Connection

Connection Description

Description

Input S

S Save the Ax to memory and return it at the analog output with a

signal at input S (Set).

Input Ax

Ax Input the analog signal to be amplified at input Ax. Use the

analog inputs, the block number of a function with analog output,

or the analog outputs.

Input R

R Reset analog output AQ to 0 with a signal at input R (Reset).

analog Output AQ is reset if S and R are both set (reset has

priority over set).

Output AQ

AQ Analog output

Value range for AQ: -32768...+32767

Example

Easy xLogic User Manual
