The connection sequence can be tracked by the change in color
of the connection lines from blue (low signal) to red (high signal).
This facilitates the detection and removal of errors significantly.
When programming in xLogicsoftware , you have the option of first
implementing your circuit program and then determining the required
unit using the Tools->Select
Tools->Select
Tools->Select
Tools->Select Hardware
Hardware
Hardware
Hardware menu command, or you can
use the tool.
The xLogic unit must be connected with the PC cable for the transfer.
All preparations have been made. The program can now be transferred.
