Easy xLogic User Manual

215
215
215
215
Model instruction
ELC-12AC-R-HMI = ELC-12AC-R+ELC-HMI , ELC-12AC-R-CAP = ELC-12AC-R+ELC-COVER
ELC-12DC-DA-R-HMI = ELC-12DC-DA-R+ELC-HMI , ELC-12DC-DA-R-CAP = ELC-12DC-DA-R+ELC-COVER
ELC-12DC-DA-TN-HMI = ELC-12DC-DA-TN+ELC-HMI, ELC-12DC-DA-TN-CAP = ELC-12DC-DA-TN+ELC-COVER
ELC-12DC-DA-TP-HMI = ELC-12DC-DA-TP+ELC-HMI, ELC-12DC-DA-TP-CAP = ELC-12DC-DA-TP+ELC-COVER
Standard
Standard
Standard
Standard CPU
CPU
CPU
CPU
Units
Units
Units
Units (ELC-12
(ELC-12
(ELC-12
(ELC-12 series)
series)
series)
series)
ELC-
ELC-
ELC-
ELC- 12
12
12
12 AC-R
AC-R
AC-R
AC-R ELC-
ELC-
ELC-
ELC- 12
12
12
12 DC-D
DC-D
DC-D
DC-D A
A
A
A -R
-R
-R
-R ELC-
ELC-
ELC-
ELC- 12
12
12
12 DC-D
DC-D
DC-D
DC-D A
A
A
A -TN
-TN
-TN
-TN ELC-
ELC-
ELC-
ELC- 12
12
12
12 DC-D
DC-D
DC-D
DC-D A
A
A
A -T
-T
-T
-T
P
P
P
P
Inputs 8 digital 8 digital 8 digital 8 digital
of which can be used in
analog mode
4 (0 to 10V) 4 (0 to 10V) 4 (0 to 10V) 4 (0 to 10V)
Input/supply voltage 110-240V AC 12-24V DC 12-24V DC 12-24V DC
Permissible range
with signal “ 0 ”
with signal “ 1 ”
Input current
85 ... 265 V AC
100 ... 253 V DC
max. 40 V AC 0.03
mA
min. 79 V AC , 0.08
mA
10.8 V ... 28.8 V DC
max. 3 V DC ,1mA
min. 8 V DC , 1.5 mA
10.8 V ... 28.8 V
DC
max. 3 V DC , 1mA
min. 8 V DC , 1.5 mA
10.8 V ... 28.8 V
DC
max. 3 V DC ,
1mA
min. 8 V DC , 1.5
mA
Outputs 4 relays 4 relays 4 transistors(PNP) 4
transistors(NPN)
Continuous current 10 A with resistive
load;
2 A with inductive
load
10 A with resistive
load;
2 A with inductive
load
0.3 A 0.3 A
Short-circuit protection External fuse
required
External fuse
required
External fuse
required
External fuse
required
Switching frequency 2 Hz with resistive
load;
0.5 Hz with
inductive load
2 Hz with resistive
load;
0.5 Hz with
inductive load
10 Hz 10 Hz
Cycle time < 0.1 ms/function < 0.1 ms/function < 0.1 ms/function < 0.1
ms/function
Integrated time
switches/
power reserve
Yes / typ. 100 h Yes / typ. 100 h Yes / typ. 100 h Yes / typ. 100 h
Connection cables 2 x 1.5 mm ² or 1 x 2.5 mm ²
Ambient temperature 0 to + 55 º C
Storage temperature – 40 º C to + 70 º C
Degree of protection IP20
Certification CE
Mounting On 35 mm standard mounting rail, 4 MW, or wall-mounting
Dimensions W x H x D ( 72 x 90 x 68 mm)
Programming cable PC cable, (RS232 or
USB)
PC cable, (RS232
or USB)
PC cable, (RS232
or USB)
PC cable, (RS232
or USB)
xLogic <=> xLogic
communication
( RS485 )
Yes Yes Yes Yes
xLogic <=> network
(Ethernet)
Yes Yes Yes Yes
Third party device(HMI)
<=> xLogic
Yes (modbus) Yes (modbus) Yes (modbus) Yes (modbus)
Maximum program
memory
512 blocks 512 blocks 512 blocks 512 blocks
Data logging Yes(ELC-MEMORY) Yes(ELC-MEMORY) Yes(ELC-MEMORY) Yes(ELC-MEMOR
Y)
Extensions Yes Yes Yes Yes
High speed input No I5,I6(14KHZ)
I7,I8(60KHZ)
I5,I6(14KHZ)
I7,I8(60KHZ)
I5,I6(14KHZ)
I7,I8(60KHZ)
High speed
output(PWM)
No No No Q3,Q4(333Hz)
HMI optional optional optional optional
