214
214
214
214
A.2
A.2
A.2
A.2 Technical
Technical
Technical
Technical data:
data:
data:
data: xLogic
xLogic
xLogic
xLogic (ELC
(ELC
(ELC
(ELC series)
series)
series)
series)
Note:
Note:
Note:
Note: The
The
The
The following
following
following
following function
function
function
function block
block
block
block cannot
cannot
cannot
cannot be
be
be
be used
used
used
used in
in
in
in ELC-6
ELC-6
ELC-6
ELC-6 series
series
series
series
Constant (Cursor key, Sms input/output,Sms message input/output)
Analog (Analog MUX, PI Controller ,Analog Ramp,Analog Math,Analog Math error detection)
Miscellaneous(Message texts, Pwm,Modbus Read,Modbus Write)
Standard
Standard
Standard
Standard CPU
CPU
CPU
CPU
Units
Units
Units
Units (ELC-6
(ELC-6
(ELC-6
(ELC-6 series)
series)
series)
series)
ELC-6AC-R
ELC-6AC-R
ELC-6AC-R
ELC-6AC-R ELC-6DC-D-R
ELC-6DC-D-R
ELC-6DC-D-R
ELC-6DC-D-R ELC-6DC-D-TN
ELC-6DC-D-TN
ELC-6DC-D-TN
ELC-6DC-D-TN
Inputs 4 digital 4 digital 4 digital
of which can be used in
analog mode
none none none
Input/supply voltage 110-240V AC 12-24V DC 12-24V DC
Permissible range
with signal 0
with signal 1
Input current
85 ... 265 V AC
100 ... 253 V DC
max. 40 V AC 0.03 mA
min. 79 V AC , 0.08 mA
10.8 V ... 28.8 V DC
max. 3 V DC ,1mA
min. 8 V DC , 1.5 mA
10.8 V ... 28.8 V DC
max. 3 V DC , 1mA
min. 8 V DC , 1.5 mA
Outputs 2 relays 2 relays 2 transistors(PNP)
Continuous current 10 A with resistive
load;
2 A with inductive load
10 A with resistive load;
2 A with inductive load
0.3 A
Short-circuit protection External fuse required External fuse required External fuse required
Switching frequency 2 Hz with resistive
load;
0.5 Hz with inductive
load
2 Hz with resistive load;
0.5 Hz with inductive load
10 Hz
Cycle time < 0.1 ms/function < 0.1 ms/function < 0.1 ms/function
Integrated time switches/
power reserve
Yes / typ. 72 h Yes / typ. 72 h Yes / typ. 72 h
Connection cables 2 x 1.5 mm ² or 1 x 2.5 mm ²
Ambient temperature 0 to + 55 º C
Storage temperature 40 º C to + 70 º C
Degree of protection IP20
Certification CE
Mounting On 35 mm standard mounting rail, 4 MW, or wall-mounting
Dimensions W x H x D (48*90*64
mm)
Programming cable PC cable, (RS232 or
USB)
PC cable, (RS232 or USB) PC cable, (RS232 or
USB)
xLogic <=> xLogic
communication ( RS485 )
No No No
xLogic <=> network
(Ethernet)
No No No
Third party device(HMI)
<=> xLogic
Yes (modbus) Yes (modbus) Yes (modbus)
Maximum program
memory
64 blocks 64 blocks 64 blocks
External memory module No No No
Data logging Yes(ELC-MEMORY) Yes(ELC-MEMORY) Yes(ELC-MEMORY)
Extensions No No No
High speed input No No No
RTC Yes Yes Yes
HMI No No No
