Easy xLogic User Manual

69
69
69
69
Parameter
Parameter
Parameter
Parameter
The time set in parameter T can be supplied by the value of another already-programmed
function:
Analog comparator: Ax - Ay
Analog trigger: Ax
Analog amplifier: Ax
Analog multiplexer: AQ
Analog ramp: AQ
Analog math: AQ
PI controller:AQ
Data latching relay: AQ
Up/Down counter: Cnt
The value of ＂ T ＂ can be set/modified in parameter mode. For information about how to
modify, refer to chapter 5 .2.2 please.
Select the required function by the block number. The timebase is configurable. For
information on valid timebase ranges and parameter preset, refer to chapter 4 .4.1 the
On-delay topic.
Timing
Timing
Timing
Timing diagram
diagram
diagram
diagram
Description
Description
Description
Description of
of
of
of the
the
the
the function
function
function
function
Output Q is set to 1 momentarily with a 0 to 1 transition at input Trg.
At the 1 to 0 transition at input Trg, xLogic retriggers the current time T, and the output
remains set. The output Q is reset to 0 when T
a
reaches the value specified in T (T
a
=T) (off
delay).
A one-shot at input Trg retriggers the time Ta.
You can reset the time Ta and the output via the input R (Reset) before the time Ta has
expired.
If retentivity is not set, output Q and the expired time are reset after a power failure.
4
4
4
4 .4.3
.4.3
.4.3
.4.3 On-/Off-delay
On-/Off-delay
On-/Off-delay
On-/Off-delay
Short
Short
Short
Short description
description
description
description
The on/off delay function is used to set an output after a configured on delay time and then
reset it again upon expiration of a second configured time.
