No parameter of Latching relay can be set/modified in parameter mode .
Timing
Timing
Timing
Timing diagram
diagram
diagram
diagram
Description
Description
Description
Description of
of
of
of the
the
the
the function
function
function
function
The status of output Q changes with each 0 to 1 transition at input Trg and if both S and R = 0,
i.e. the output is switched on or off.
Input Trg does not influence the SFB when S = 1 or R = 1.
A one-shot at input S sets the pulse relay, i.e. the output is set to logical 1.
A one-shot at input R resets the pulse relay to its initial state, i.e. the output is set to logical 0.
Either the input R takes priority over input S (i.e. the signal at input S has no effect as long as
R = 1), or the input S takes priority over input R (i.e. the signal at input R has no effect as long
as S = 1), depending on your configuration.
4
4
4
4 .4.18
.4.18
.4.18
.4.18 Message
Message
Message
Message text
text
text
text
Short
Short
Short
Short description
description
description
description
Display parameterized message texts and parameters of other blocks in RUN mode.
Input Trg
Trg
Trg
Trg You switch output Q on or off with a signal at input Trg
(Trigger) input.
Input S
S
S
S A one-shot at input S (Set) sets the output to logical 1.
Input R
R
R
R A one-shot at input R (Reset) resets the output to logical 0
Parameter Selection:
Selection:
Selection:
Selection:
RS (input R priority), or
SR (input S priority)
Retentivity
Retentivity
Retentivity
Retentivity set (on) = the status is retentive in memory.
Output Q
Q
Q
Q Q is switched on with a signal at Trg and is reset again at
the next Trg pulse, if both S and R = 0.
Connection
Connection
Connection
Connection Description
Description
Description
Description
Input En
En
En
En A 0 to 1 transition at En (Enable) triggers the output of the
message text.
Input P
P
P
P P is the priority of the message text.
1 is the lowest, 32 is the highest priority.
Quit: Acknowledgement of the message text
Parameter Text:
Text:
Text:
Text: Input of the message text
Par:
Par:
Par:
Par: Parameter or actual value of another, already
configured function (see "Visible parameters or
actual values")
Time:
Time:
Time:
Time: Shows the continuously updated time-of-day
Date:
Date:
Date:
Date: Shows the continuously updated date
EnTime:
EnTime:
EnTime:
EnTime: Shows the time of the 0 to 1 transition
EnDate:
EnDate:
EnDate:
EnDate: Shows the 0 to 1 transition of the date
Output Q
Q
Q
Q Q remains set as long as the message text is queued.
