Communication
Bay
USB
Port
RS-232
Port
REPO
Port
Relay
Port
5-15P
Input Cord
(6) 5-15R
Output Receptables
Specifications
Eaton 9130 700/3000 VA UPS User’s Guide 164201718—Rev 7 www.eaton.com/powerquality 74
Figure 43. Model PW9130L700T-XL
Communication
Bay
USB
Port
RS-232
Port
5-15P
Input Cord
REPO
Port
Relay
Port
(6) 5-15R
Output Receptables
EBM
Connection
Figure 44. Model PW9130L1500T-XL
