Communication
Bay
USB
Port
RS-232
Port
REPO
Port
Relay
Port
5-15P
Input Cord
(6) 5-15R
Output Receptables
EBM
Connection
Specifications
Eaton 9130 700/3000 VA UPS User’s Guide 164201718—Rev 7 www.eaton.com/powerquality 75
Figure 45. Model PW9130L1000T-XL
RS-232
Port
USB
Port
Communication
Bay
REPO
Port
Relay
Port
5-20P
Input Cord
(4) 5-20T
Output Receptables
(1) L5-20R
Output
Receptable
EBM
Connection
Figure 46. Model PW9130L2000T-XL
