Eaton 9130 - Page 84

Communication
Bay
USB
Port
RS-232
Port
REPO
Port
Relay
Port
IEC C14-10A
Input Connector
(6) IEC 320-10A
Output Receptables
Specifications
Eaton 9130 700/3000 VA UPS User’s Guide 164201718—Rev 7 www.eaton.com/powerquality 78
Figure 51. Model PW9130i700T
RS-232
Port
USB
Port
Communication
Bay
REPO
Port
Relay
Port
IEC C14-10A
Input Connector
(6) IEC 320-10A
Output Receptables
EBM
C
onnection
Figure 52. Model PW9130i1500T-XL
