Eaton MMX11 Series - Modbus Parameters

Serial interface (Modbus RTU)
04/10 MN04020001Z-EN
136
Modbus parameters
The following table shows the Modbus parameters in the M-
Max
TM
.
RUN Indicates the access right during operation (FWD or REV)
- = No parameter change possible,
/ = Parameter change possible.
ro/rw Indicates the access right via the fieldbus
ro = Read only possible,
rw = Read and write possible.
PNU ID Access right Designation Value range FS
(P1.3)
RUN ro/rw
S2.1 808
1)
- ro Communication status Format xx.yyy
xx = Number of received faulty messages (0 - 64).
yyy = Number of received correct messages (0 -
999).
0.000
1)
S2.2 809
1)
/ rw Field bus protocol 0 = field bus deactivated
1 = Modbus
0
1)
S2.3 810
1)
/ rw Slave address 1 - 255 1
1)
S2.4 811
1)
/ rw Baud rate 0=300
1=600
2 = 1200 (1.2 k Baud)
3 = 2400 (2.4 k Baud)
4 = 4800 (4.8 k Baud)
5 = 9600 (9.6 k Baud)
6 = 19200 (19.2 k Baud)
7 = 38400 (38.4 k Baud)
8 = 57600 (57.6 k Baud)
5
1)
S2.6 813 / rw Parity type 0=None l 2 Stop bits
1=Even l 1 Stop bit
2=Odd l 1 Stop bit
0
1) When the fieldbus is connected (option, e.g. CANopen, PROFIBUS DP etc:) modified ID numbers and different factory settings are stored here. Detailed
information is provided in the specific manuals of the relevant fieldbus interface module.
S2.7
814 / rw Timeout up to fieldbus
error (error 53) if no master
messages are received
although Modbus is still
active.
0 = Not used
1=1s
2=2s
...255 = to 255 s
0
S2.8
815 / rw Reset communication
status
xx and yyy are reset to 0
0 = Not used
1 = resets parameter S2.1
0
Drives control
P6.1
125 / rw Control place 1 1 = Control signal terminals (I/O)
2 = Control unit (KEYPAD)
3 = Interface (BUS)
1
P6.2 117 / rw Setpoint Source 0 = Fixed frequency (FF0)
1 = Control unit (KEYPAD)
2 = Interface (BUS)
3 = AI1 (analog setpoint 1)
4 = AI2 (analog setpoint 2)
3
