Key to part numbers
The type designation code and the part no. of the M-MAX
TM
frequency inverter series are in the following order:
Figure 5: Type designation of the M-Max
TM
frequency inverters
MMX 3 4 AA 1D3 F 0 -0 Explanation
0 = No optional assembly integrated
1 = Optional assembly integrated
0 = IP20 protection type
1 = Protection type IP21, NEMA 1
F = Radio noise filter (internal)
N = Without internal radio noise filter (No filter)
Rated operational current
1D3 = 1.3 A (D = decimal)
011 = 11 A
AA = Specification (Software version, display unit)
Voltage class
1 = 100 V (110 V -15 % - 115 V +10 %)
2 = 200 V (208 V -15 % - 240 V +10 %)
4 = 400 V (380 V -15 % - 480 V +10 %)
1 = Single-phase power supply
3 = Three-phase mains supply voltage
MMX = frequency inverter of the M-Max
TM
series
