Parameter menu (PAR)
73
Parameter selection (P1)
In the parameter selection (P1), you can choose between the
factory set quick configuration (P1.1 = 1) with a reduced
parameter set and all parameters (P1.1 = 0).
The setting of the parameters with the quick configuration
(P1.1 = 1) is guided by a Quickstart Wizard (see Section
“Parameter menu (PAR)”, page 71). Each executed parameter
must be processed in succession up to frequency display M1.1.
A return to a previous parameter is not possible here. The preset
application parameters are selected under P1.2. Only when the
quick-start assistant (M1.1) is completed can the parameters be
called again and then also individually.
h
With P1.1 = 0 (all parameters) and P1.2 = 0, 1, 2 or 3, you
can link the predefined application values with all
parameters.
h
Every single parameter value is reset to factory settings
every time that the application menu is activated.
PNU ID Access right
RUN
Value Description Factory setting
(P1.3)
P1.1 115 / Parameter conceal 1
0 All Parameters.
All parameters are shown and can be changed.
1 Only quick configuration parameters.
Only the selected parameters of the quick configuration are shown
and can be changed.
P1.2 540 - Drive Setup
a Listing of the preset application parameters, table 8, page 74.
0
0 Base
1 Pump drive
2 Fan drive
3 Hoisting device (high load)
P1.3 1472 - Country specific default settings (FS) 0
0 EU (Europe, 50 Hz networks)
1 USA (North America, 60 Hz networks)
The country specific factory setting takes into account the
frequency based parameters in relation to 50 and 60 Hz networks:.
PNU Designation P1.3 = 0 P1.3 = 1
P6.4 Maximum frequency 50 Hz 60 Hz
P7.3 Motor, rated speed 1440 rpm 1720 rpm
P7.6 Motor, rated frequency 50 Hz 60 Hz
P11.2 Cut-off frequency 50 Hz 60 Hz
P11.4 U/f characteristic curve,
mean frequency value
25 Hz 30 Hz
P14.3 Motor (2PS) nominal
speed
1440 rpm 1720 rpm
P14.6 Motor (2PS) nominal
frequency
50 Hz 60 Hz
P14.8 Maximum frequency
(2PS)
50 Hz 60 Hz
