Parameters
04/10 MN04020001Z-EN
72
Quickstart Wizard
The quick-start assistant guides you in the quick configuration
through all important settings that have to be made or that you
should check for your application (see A in figure 67). The
parameters that are called during the process are listed in table 8,
page 74 in column "Basic (Standardoperation)".
When the quick configuration is completed, the frequency display
M1.1 is activated automatically. Selecting the PAR main menu
again enables you to call up the parameters of the quick
configuration and then change them freely.
Besides the parameters of the quick-configuration, system
parameters S1.1 to S4.3 are also shown after the first setting.
P1.1 = 0 activates access to all parameters and the full
functionality of all buttons of the keypad (free parameter
definition, see B infigure 67).
This exits the quick-configuration and the guided setup with the
quick-start assistant.
h
The process is run from parameter to parameter.
Returning is not possible here.
In the quick-configuration, the OK button activates
the individual parameter values and then moves on
to the next parameter. Every parameter always
shows the value that is set in alternating sequence.
By actuating the OK button again, you activate the
value (value flashes).
The arrow buttons have a restricted
functionality (change of parameter values
and cursor control) in the quick-start
configuration.
OK
