Eaton MMX11 Series User Manual

Appendix
04/10 MN04020001Z-EN
158
Table 12: Specified fuses
Part no.
M-Max
TM
Maximum permitted
mains supply voltage
2) 3)
U
LN
VDE UL
1)
Part no. Moeller
[V] [A] [A]
MMX11AA1D7… 1 AC 120 V +10 % 20 20 FAZ-B20/1N -
MMX11AA2D4… 1 AC 120 V +10 % 20 20 FAZ-B20/1N -
MMX11AA2D8… 1 AC 120 V +10 % 20 20 FAZ-B20/1N -
MMX11AA3D7… 1 AC 120 V +10 % 20 20 FAZ-B20/1N -
MMX11AA4D8… 1 AC 120 V +10 % 32 30 FAZ-B32/1N -
MMX12AA1D7…
1 AC 240 V +10 % 10 10 FAZ-B10/1N -
MMX12AA2D4… 1 AC 240 V +10 % 10 10 FAZ-B10/1N -
MMX12AA2D8… 1 AC 240 V +10 % 10 10 FAZ-B10/1N -
MMX12AA3D7… 1 AC 240 V +10 % 10 10 FAZ-B101/N -
MMX12AA4D8… 1 AC 240 V +10 % 20 20 FAZ-B20/1N -
MMX12AA7D0… 1 AC 240 V +10 % 20 20 FAZ-B20/1N -
MMX12AA9D6… 1 AC 240 V +10 % 32 30 FAZ-B32/1N -
MMX32AA1D7… 3 AC 240 V +10 % 6 6 FAZ-B6/3 PKM0-6.3
MMX32AA2D4… 3 AC 240 V +10 % 6 6 FAZ-B6/3 PKM0-6.3
MMX32AA2D8… 3 AC 240 V +10 % 6 6 FAZ-B6/3 PKM0-6.3
MMX32AA3D7… 3 AC 240 V +10 % 6 6 FAZ-B6/3 PKM0-6.3
MMX32AA4D8… 3 AC 240 V +10 % 10 10 FAZ-B10/3 PKM0-10
MMX32AA7D0… 3 AC 240 V +10 % 10 10 FAZ-B10/3 PKM0-10
MMX32AA011…
3 AC 240 V +10 % 20 20 FAZ-B20/3 PKM0-20
MMX34AA1D3…
3 AC 480 V +10 % 6 6 FAZ-B6/3 PKM0-6.3
MMX34AA1D9…
3 AC 480 V +10 % 6 6 FAZ-B6/3 PKM0-6.3
MMX34AA2D4… 3 AC 480 V +10 % 6 6 FAZ-B6/3 PKM0-6.3
MMX34AA3D3… 3 AC 480 V +10 % 6 6 FAZ-B6/3 PKM0-6.3
MMX34AA4D3… 3 AC 480 V +10 % 10 10 FAZ-B10/3 PKM0-10
MMX34AA5D6…
3 AC 480 V +10 % 10 10 FAZ-B10/3 PKM0-10
MMX34AA7D6…
3 AC 480 V +10 % 20 20 FAZ-B20/3 PKM0-20
MMX34AA9D0… 3 AC 480 V +10 % 20 20 FAZ-B20/3 PKM0-20
MMX34AA012… 3 AC 480 V +10 % 20 20 FAZ-B20/3 PKM0-20
MMX34AA014… 3 AC 480 V +10 % 25 25 FAZ-B25/3 PKM0-25
1) Fuse UL-rated, class J, 600 V
2) I
cn
10 kA
3) I
cn
50 kA
