Eaton MMX11 Series User Manual

Appendix
04/10 MN04020001Z-EN
168
Table 17: Rating and short-time rating
Table 18: Assignment of brake resistors to the M-MaxTM frequency inverters with the permissible ED values (example): “Device series MMX34“, page 150
BR...
R
B
P
DB
P
max
PDB (UL
®
) P
max
(UL
®
)
[O] [W] [kW] [W] [kW]
BR10361K0-T-PF 36 1000 20 800 16
BR1036500-T-PF 36 500 10 400 8
BR10561K0-T-PF 56 1000 20 800 16
BR1056300-T-PF 56 300 6 250 5
BR1056800-T-PF 56 800 16 600 12
BR30362K4-T-PF 36 2450 24.5 2100 21
BR30362K8-T-PF 36 2800 28 2750 27.5
BR30363K6-T-PF 36 3600 36 3400 34
BR2047240 47 240 4 800 16
BR2060200 60 200 1.8 400 8
BR2036400-T-SAF
36 400 3.6 800 16
BR2047240-T-SAF 47 240 4 250 5
BR2060200-T-SAF 60 200 1.8 600 12
BR2065400-T-SAF 65 400 4 2100 21
BR2075480-T-SAF 75 480 8 2750 27.5
MMX34...
3D3 4D3 5D6 7D6 9D0 012 014
Permissible R
min
55 O 55 O 55 O 35 O 35 O 35 O 35 O
Duty factor ED ED ED ED ED ED ED
[%] [%] [%] [%] [%] [%] [%]
BR2047240 - - - 10 - - -
BR2060200 10 10 10 - - - -
BR2036400-T-SAF - - - - 10 10
BR2047240-T-SAF - - - 10 - - -
BR2060200-T-SAF
10 10 10 - - - -
BR2065400-T-SAF
25 25 - - - - -
BR2075480-T-SAF - - 25 - - - -
BR10361K0-T-PF - - - 30 25 14 10
BR1036500-T-PF - - - 13 10 7 5
BR10561K0-T-PF 55 55 40 7 5 - -
BR1056300-T-PF 15 15 10 7 5 - -
BR1056800-T-PF 35 35 25 18 13 10 7
BR30362K4-T-PF - - - 50 40 30 20
BR30362K8-T-PF - - - 60 45 33 25
BR30363K6-T-PF - - - 100 75 55 40
