Eaton S811+N37 series User Manual

Technical Data and Specifications
4 S811+ Soft Starter MN03900001E—November 2012
Short-Circuit Ratings—Component
Short-Circuit Ratings—Enclosed Control (Fuses)
Short-Circuit Ratings—Enclosed Control (Breaker)
Frame Size Fuses Circuit Breaker Voltage SCCR Rating (A)
S811+N… J HFD 600 10 kA
S811+R… RK5/J HFD,HKD 600 10 kA
S811+T… RK5/J HLD 600 18 kA
S811+U… RK5/J HLD 600 30 kA
S811+V… L HND, RD 600 42 kA
Frame Size Fuses Voltage
SCCR
Rating (A)
Switch
Size (max), A Switch Type
S811+N… J 600 100 kA 100 K
S811+R… RK5/J 600 100 kA 200 K
S811+T… RK5/J 600 100 kA 600 K
S811+U… RK5/J 600 100 kA 600 K
S811+V36… RK5/J 600 100 kA 600 K
S811+V42… L 600 100 kA 800 K
S811+V50… L 600 100 kA 800 K
S811+V72… L 600 100 kA 1200 ND
S811+V85… L 600 100 kA 1200 ND
S811+V10… L 600 100 kA 2000 K
Frame Size
Thermal Magnetic
Circuit Breaker
Motor Circuit
Protector Voltage
SCCR
Rating (A)
Max Size
(breaker) A
S811+N… HFD HMCP 600 10 kA 150
S811+R… HFD,HKD HMCP 600 10 kA 150, 300
S811+T… HLD HMCP 600 18 kA 600
S811+U… HLD HMCP 600 18 kA 600
S811+V… HND, RD HMCP 600 35 kA, 42 kA 1000, 2000
