Installation

S811+ Soft Starter MN03900001E—November 2012 9

Approximate Dimensions in inches (mm)

S811+T…

S811+U…

11.77

(299.0)

12.71

(322.9)

6.47 (164.4)

7.65 (194.4)

5.40

(137.3)

5.95

(151.1)

5.91 (150.0)

0.28

(7.1)

6X Ø

2.95

(75.0)

7.16 (181.8)

6X Ø

12.72

(323.1)

11.77

(299.0)

6.09

(154.8)

6.64

(168.6)

2.60

(66.0)

0.28

(7.1)

5.20 (132.0)

7.73 (196.3)
